| Model |
5038.S |
| Drive |
6×4 |
| ENGINE |
| Engine Type |
Cummins ISLe 375 |
| Max power |
375 HP at 2100 RPM |
| Max torque |
1550 Nm at 1200-1400 RPM |
| Clutch |
430mm – Single plate Dry Friction Type |
| Gear box |
EATON FSO10309 |
| Rear Axle Ratio |
4.55/5.57 |
| Crawler Ratio |
10.58 |
| BRAKE |
| Brake Type |
Dual Air Circuit- S Cam with ABS |
| Auxillary Braking System |
Jake Brake |
| Suspension Type
|
Front Suspension – Parabolic Leaf Spring
Rear Suspension – Semi Elliptical Leaf Spring |
| DIMENSIONS |
| Wheel base (mm) |
4275 |
| Min. TCD (mm) |
14120 |
| Ground Clearance(mm) |
250 |
| Vehicle Overall Length (mm) |
7350 |
| Vehicle Overall Width(mm) |
2545 |
| Overall Height (Unladen)(mm) |
3310 |
| WEIGHTS |
| Max GCW (Kg) |
50000 |
| Max. FAW (Kg) |
6000 |
| Max. RAW (Kg) |
23000 |
| Tare Weight (Cabin/Chassis) |
9400 |
| PERFORMANCE
|
| Max.Greadability at 1st Gear |
16% |
| Top Speed(Kmph) |
120 |
| Fuel Tank Capacity (L) |
300 |
| 5th Wheel Coupling Size |
2” |
